8 Configuration
8.1 Analog inputs “InP”
InP: Analog input
Depending on the instrument version, up to two analog inputs are available.
Configuration
Analog inputs
Controller
Generator
Limit comparators
Outputs
Binary functions
Display
Timer
Interfaces
H
The approval according to DIN EN 14597 requires the usage of probes, also
approved to DIN EN 14597, in the specified temperature ranges.
v see data sheets T90.1006 and T90.2006
Analog input 1 InP1 ➔
Analog input 2
InP2 ➔
Symbol Value/selection Description
Sensor type
SEnS
0
1
2
3
4
5
6
7
8
9
10
11
no function
Resistance thermometer in 3-wire circuit
Resistance thermometer in 2-wire circuit
Resistance thermometer in 4-wire circuit
Thermocouple
Resistance transmitter
Heater current 0—50mA AC (analog input 2 only)
0—20mA
4—20mA
0—10V
2—10V
0—1V
factory-set on analog input 2: no function
Linearization
Lin
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Linear
Pt100
Pt500
Pt1000
KTY11-6
W5Re_W26Re C
W3Re_W25Re D
NiCr-Con E
Cu-Con T
Fe-Con J
Cu-Con U
Fe-Con L
NiCr-Ni K
Pt10Rh-Pt S
Pt13Rh-Pt R
Pt30Rh-Pt6Rh B
NiCrSi-NiSi N
W3Re_W26Re
customized linearization
For customized linearization, a maximum of 10 knee-points
can be implemented, or a 5th order polynomial function
programmed (only through the setup program).
For the linearization “KTY11-6”, the resistance is 2kΩ at 25°C
(only through the setup program).
Factory settings are shown bold.
