8 Configuration
8.7 Display “diSP”
diSP: Display
The values displayed can be matched to the existing requirements.
Furthermore, time-out and level inhibit can be configured here.
Configuration
Analog inputs
Controller
Generator
Limit comparators
Outputs
Binary functions
Display
Timer
Interfaces
Symbol Value/selection Description
General
Upper display
d iSU
(analog selector)
process value
Displayed value for the upper display
Lower display
d iSL
(analog selector)
present setpoint
Displayed value for the lower display
Decimal point
dEcP
0
1
2
no decimal place
one decimal place
two decimal places
If the value that is be displayed can no longer be represented
with the programmed decimal point, then the number of
decimal places will be automatically reduced. If, subsequently,
the measured value decreases, the number increases to the
programmed value of the decimal point.
16-segment display
diSt
0
1
2
3
4
Displayed value for the two-digit 16-segment display
switched off
Unit (°C or °F)
current segment
current parameter set
text (only setup program)
Brightness (setup) 0…5 (bright) 0—5 (dark)
Time-out (setup) 0…180…255s Time period, after which the instrument automatically returns
to normal display if no key is pressed.
Level inhibit (setup) none
configuration level
parameter/
configuration level
operator/
parameter/
configuration level
The access to the individual levels can be inhibited.
The setting is independent of the binary function “level inhibit”.
Inhibiting the parameter level will, at the same time, also inhibit
the start of autotuning.
User data (setup program)
Up to eight parameters from different levels can be shown under User data (operator level) on
the instrument and edited. The symbols for these parameters (shown in the lower display)
must be assigned by the user himself.
Factory settings are shown bold.
