8.5 Outputs “OutP”
OutP: Outputs
Configuration of the instrument outputs are subdivided into analog outputs (OutA;
max. 2) and binary outputs (OutL; max. 9). Binary outputs are relay, solid-state relay
and logic outputs. Display and numbering of the outputs depends on the assignment
of the option slots.
The switching states of the binary outputs 1—6 are shown in the display.
Numbering of the
outputs
Standard for all instrument versions:
(Binary) output 1 (Out1) = relay
(Binary) output 2 (Out2) = relay
(Binary) output 3 (Out3) = logic output
(Binary) output 4 (Out4) = logic output
Extended numbering for the option slots:
Configuration
Analog inputs
Controller
Generator
Limit comparators
Outputs
Binary functions
Display
Timer
Interfaces
Slot Plug-in board with
1 analog output
Plug-in board with
1 binary output
(relay or solid-state
relay)
Plug-in board with
2 binary outputs
(2 relays)
Option 1 Output 5 (Out5) Output 5 (Out5) Output 5+8 (Out5/Out8)
Option 2 Output 6 (Out6) Output 6 (Out6) Output 6+9 (Out6/Out9)
Option 3 Output 7 (Out7) Output 7 (Out7) Output 7+10 (Out7/Out0)
Binary outputs 0utL
Symbol Value/selection Description
Binary output 1
0ut1
0
1
2
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
no function
Controller output 1 (ex-factory with Out1)
Controller output 2
Binary input 1
Binary input 2
Binary input 3
Binary input 4
Binary input 5
Binary input 6
Binary input 7
Binary input 8
Limit comparator 1
Limit comparator 2
Limit comparator 3
Limit comparator 4
Control contact 1
Control contact 2
Control contact 3
Control contact 4
Logic formula 1
Logic formula 2
Timer 1 active
Timer 2 active
Program active
Program end signal
Tolerance limit signal
Manual mode on/off
Binary marker
Any binary value from storage address (only through setup)
always active
...
...
Binary output 10
0ut0
Factory settings are shown bold.
