5 Operation
30
5.6 Program controller
Condition as
delivered
The instrument must be configured as a program controller/generator. Furthermore, a
program must be entered beforehand, to operate the instrument as a program
controller/generator.
5.6.1 Entering programs
Function A setpoint profile can be implemented with a maximum of 8 program segments.
Entry on the
instrument
The instrument must be configured as a program controller/generator.
v Chapter 8.3 “Generator “Pro”” (Function)
Configurable time base: mm:ss, hh:mm und dd:hh (s=seconds, m=minutes, h=hours,
d=days).
v Chapter 8.3 “Generator “Pro”” (unit)
The settings for segment setpoints (SPP1 — SPP8) and segment times (tP1 — tP8)
are made in the program editor.
