JUMO 703041 - Page 73

73
12 Appendix
Electrical data
Housing
Interface
Approvals/marks of conformity
Supply voltage (switchmode PSU) 110 — 240V AC -15/+10%, 48 — 63Hz
20—30V AC/DC, 48—63Hz
Electrical safety Type 703041: to EN 61010, Part 1
Type 703042/43/44: to EN 60730
Overvoltage category III, pollution degree 2
Power consumption Type 703041: 8VA max.
Type 703042/43/44: 13VA max.
Data backup EEPROM
Electrical connection at the back, via screw terminals,
conductor cross-section up to 2.5mm
2
with core ferrules (length: 10 mm)
Electromagnetic compatibility
interference emission
interference immunity
EN 61326-1
Class B
to industrial requirements
Housing type plastic housing for panel mounting to IEC 61554
Depth behind panel 90 mm
Ambient/storage temperature range 0 to 55°C / -30 to +70°C
Climatic conditions rel. humidity ≤90% annual mean, no condensation
Operating position horizontal
Enclosure protection to EN 60 529, front IP65 / back IP20
Weight (fully fitted) Type 703041: approx. 220g
Type 703042/43: approx. 380g
Type 703044: approx. 490g
Modbus
Interface type RS422/485
Protocol Modbus, Modbus Integer
Baud rate 9600, 19200, 38400
Device address 0 — 255
Max. number of nodes 32
PROFIBUS-DP
Device address 0 — 255
Mark of
conformity
Testing laboratory Certificates/certification
numbers
Test basis valid for
DIN DIN CERTCO Register No. TR1187 DIN EN 14597 all types
GL - Hardware
GL - Software
Germanischer Lloyd Type Approval Certificate
No. 45 059-07 HH
GL-Approval
Category C, EMC1
703044/191-320-23/
214, 062
c UL us Underwriters Laboratories E 201387 UL 61010-1
CAN/CSA-C22.2 No. 61010-1
all types
Conductor cross-sections and core-end ferrules for installation
Minimum
cross-
section
Maximum
cross-
section
Min. length of
core-end ferrule
Without core-end ferrule 0.34mm
2
2.5mm
2
10mm
(stripped)
Core-end ferrule, no lip 0.25mm
2
2.5mm
2
10mm
Core-end ferrule, lip up to
1.5mm
2
0.25mm
2
1.5mm
2
10mm
Core-end ferrule, lip above
1.5mm
2
1.5mm
2
2.5mm
2
12mm
Twin ferrule with lip 0.25mm
2
1.5mm
2
12mm
