Juniper CTP Series User Manual

0) Back to Previous Menu
1) NetRef: Slave
2) NetRef Master IP (Priority 1): 10.216.118.73
3) NetRef Master IP (Priority 2): 10.216.118.86
4) NetRef Master IP (Priority 3): 10.216.118.90
5) NetRef Master IP (Priority 4): 10.216.118.88
------------ Your choice [5]:
NOTE: When a node is configured for NetRef backup operation, the remote
address must be configured to that of the primary node. Likewise, the NetRef
primary node must be configured with the IP address of the NetRef backup
node. A NetRef primary node can be configured to send data packets to up
to 10 NetRef backup nodes.
Rate selection and clock configuration allow the serial interface rate to be
configured through the software. Rates supported range from less than 300
bps to 12.288 Mbps (in subhertz increments). You can configure the CTP
systems by using the menu interface to provide multiple prioritized node
clock references. An external reference input and any of the serial interfaces
may be used for the node reference clock. Reference frequencies must be 32
KHz, n x 64 KHz, or 1,544 KHz up to a maximum of 4096 KHz (2048 KHz
maximum on the CTP1002).
Follow the onscreen instructions and configure the options as described
inTable 54 on page 127.
Table 54: Configuring Multiple NetRef Master Node IP Addresses
Your ActionFunctionField
Enter 2, 3, 4, and 5 to configure NetRef master nodes
with priorities 1, 2, 3, and 4, respectively.
Specifies whether you want to configure
multiple master nodes with priorities,
which can be used to transmit clocking
information to the backup nodes in NetRef.
NetRef Master IP
(Priority)
Specify y or n.Specifies whether you want to configure a
NetRef master node.
Configure a NetRef
Master? n[y]
Specify IP address of the NetRef master node assigned
with different priorities.
Specify rtn to set the IP address of 127.0.0.1 interface
that is prompted by the system to be specified as the
default IPv4 address of the master node. For example,
if the prompt displays (rtn for 127.0.0.1), and if you
specify rtn, 127.0.0.1 is set as the default IP address.
Specifies the IP address of the NetRef
master node..
Enter remote node IP
address for NetRef
Related
Documentation
Configuring NetRef for Adaptive Bundle Operation on page 120•
• Network Node Reference Overview on page 118
127Copyright © 2018, Juniper Networks, Inc.
Chapter 2: Configuring CTP Bundles
