Page #52 background imageLoading...
Page #52 background image
Table 19: CTP Bundle Signaling Settings in CTPView (continued)
Your ActionFunctionField
Select one:
Fixed - ON/0/Space/Low—Signal is turned on.
Fixed - OFF/1/Mark/High—Signal is turned off.
InBand - From Remote RL—Output signal is based on the state
of the RL input signal from the DCE or the TM signal from the
DTE.
InBand - From Remote RTS—Output signal is based on the state
of the RTS input signal from the DCE or the CTS signal from the
DTE.
InBand - From Remote DTR—Output signal is based on the state
of the DTR input signal from the DCE or the DSR signal from the
DTE.
InBand - From Remote LL—Output signal is based on the state
of the LL input signal from the DCE or the DCD signal from the
DTE.
Specifies the output signal depending
on whether the bundle is configured as
the DCE or the DTE:
DCE—CTS output signal.
DTE—RTS output signal.
Signal Out -
CTS/RTS
Select one:
Fixed - ON/0/Space/Low—Signal is turned on.
Fixed - OFF/1/Mark/High—Signal is turned off.
InBand - From Remote RL—Output signal is based on the state
of the RL input signal from the DCE or the TM signal from the
DTE.
InBand - From Remote RTS—Output signal is based on the state
of the RTS input signal from the DCE or the CTS signal from the
DTE.
InBand - From Remote DTR—Output signal is based on the state
of the DTR input signal from the DCE or the DSR signal from the
DTE.
InBand - From Remote LL—Output signal is based on the state
of the LL input signal from the DCE or the DCD signal from the
DTE.
Specifies the output signal depending
on whether the bundle is configured as
the DCE or the DTE:
DCE—DCD output signal.
DTE—LL output signal.
Signal Out -
DCD/LL
Select one:
Fixed - ON/0/Space/Low—Signal is turned on.
Fixed - OFF/1/Mark/High—Signal is turned off.
InBand - From Remote RL—Output signal is based on the state
of the RL input signal from the DCE or the TM signal from the
DTE.
InBand - From Remote RTS—Output signal is based on the state
of the RTS input signal from the DCE or the CTS signal from the
DTE.
InBand - From Remote DTR—Output signal is based on the state
of the DTR input signal from the DCE or the DSR signal from the
DTE.
InBand - From Remote LL—Output signal is based on the state
of the LL input signal from the DCE or the DCD signal from the
DTE.
Specifies the output signal depending
on whether the bundle is configured as
the DCE or the DTE:
DCE—TM output signal.
DTE—RL output signal.
Signal Out -
TM/RL
Copyright © 2018, Juniper Networks, Inc.46
Using Bundles to Create Logical Configurations for Physical Interfaces, CTP Release 7.3, CTPView Release 7.3
