Table 19: CTP Bundle Signaling Settings in CTPView (continued)
Your ActionFunctionField
Select one:
•
Unused—Input signals are ignored.
•
Demand Call - Active High—Signal is turned off.
•
Demand Call - Active Low—Signal is turned on.
Specifies the input signal depending on
whether the bundle is configured as the
DCE or the DTE:
•
DCE—RL input signal.
•
DTE—TM input signal.
Signal In -
RL/TM
Select one:
•
Unused—Input signals are ignored.
•
Demand Call - Active High—Signal is turned off.
•
Demand Call - Active Low—Signal is turned on.
Specifies the input signal depending on
whether the bundle is configured as the
DCE or the DTE:
•
DCE—RTS input signal.
•
DTE—CTS input signal.
Signal In -
RTS/CTS
Select one:
•
Unused—Input signals are ignored.
•
Demand Call - Active High—Signal is turned off.
•
Demand Call - Active Low—Signal is turned on.
Specifies the input signal depending on
whether the bundle is configured as the
DCE or the DTE:
•
DCE—DTR input signal.
•
DTE—DSR input signal.
Signal In -
DTR/DSR
Select one:
•
Unused—Input signals are ignored.
•
Demand Call - Active High—Signal is turned off.
•
Demand Call - Active Low—Signal is turned on.
Specifies the input signal depending on
whether the bundle is configured as the
DCE or the DTE:
•
DCE—LL input signal.
•
DTE—DCD input signal.
Signal In -
LL/DCD
