JVC CL-S500 Series

- 29 -
The supplied USB cable can also be used for the followings:
• To calibrate the monitor (An optional calibration kit is required.)
• To calibrate multiple monitors in succession
●
To calibrate the monitor
Connect the supplied USB cable between one of the monitor’s UP’s and the
workstation’s USB down port. For more information, refer to the instruction manual
for the calibration kit.
●
To calibrate multiple monitors in succession
Up to 6 monitors can be connected one after another in a daisy chain using USB
cables.
1
Connect the supplied USB cable between the rst monitor’s USB UP and the
workstation’s USB port.
2
Connect a USB cable between the rst monitor’s USB DOWN and the second
monitor’s USB UP.
3
Repeat step 2 until all monitors are connected one after another.
3rd
2nd 1st
Workstation
6th
5th 4th
