JVC CL-S500 Series Installation Manual

- 16 -
Setting the conguration data
CL-S500 can save up to three settings of luminance-Gamma-color as conguration data
within the monitor and they can be switched by selecting a conguration number
appeared on the current operating state OSD screen. The following three conguration
settings are saved prior to shipping as factory default.
Conguration
number
Luminance (cd/m
2
)
Color Gamma Shipping setting
Max. Min.
1 500 0.6 7500 K * DICOM GSDF Japan, Europe, Korea
2 500 1 7500 K * DICOM GSDF North America
3 500 0.6 7500 K * EXP. 2. 2
－
*
:
x0.299, y0.315
Note
To set and save conguration data other than above, an optional
calibration kit is required.
Setting method 1
You can switch the conguration data by OSD.
1) Display the “Operation Button Guide
①
” by pressing any one of operation buttons
(A–C).
2) Press the “MENU” button.
3) Select “CONFIGURATION” from MENU 1/2 using the “▼” or “▲” button and press the
“OK” button. Then select “Cong1”, “Cong2” or “Cong3” from “CONFIGURATION”
OSD and press the “OK” button.
Setting method 2
You can assign the switching of the conguration data to the function buttons (F1 or
F2) which allows you to switch easily via button operation. The following explains how
to assign to the “F2” button.
1) Display the “Operation Button Guide
①
” by pressing any one of operation buttons
(A–C).
2) Press the “MENU” button.
3) Select “FUNCTION” from MENU 1/2 using the “▼” or “▲” button and press the “OK”
button. Then select “FUNCTION2” from “FUNCTION” OSD and press the “OK”
button.
4) Select “CONFIGURATION” from “FUNCTION2” OSD and press the “OK” button.
5) Display the “Operation Button Guide
①
” by pressing any one of operation buttons
(A–C).
6) Press the “F2” button to select “Cong1”, “Cong2” or “Cong3” from
“CONFIGURATION” OSD.
You can check the “CALIBRATION SETTING” status of “CURRENT STATE”.
