- 14 -
Performing the DICOM
conformance test
Note
This function is available only when the monitor has been calibrated to DICOM GSDF.
Performing the DICOM conformance test ensures DICOM conformance of the monitor
by measuring and checking the monitor properties.
The DICOM conformance test is recommended to be performed after 60 minutes of
continuous lighting time of the backlight of the LCD panel. If the test is performed in
less than 60 minutes of lighting time, a margin of measurement error may be larger
because luminance is not stable enough.
Procedures of DICOM conformance te󰎣
1) Display the “Operation Button Guide ” by pressing any one of operation buttons
(A–C).
2) Press the “MENU” button.
3) Select “CURRENT STATE” from MENU 1/2 using the “▼” or “” button and press the
OK” button.
4) Make sure the gamma is set to “DICOM GSDF”.
5MP
DICOM CONF ORMA NCETEST
RESULT :---
MA X DE VIATION : ---
LUMI NANCE :Stable
EL APSED TIME :123 m in
STA RT TE S TI N G
Y e s
>N o
Result of the last test
( “---” indicates that the test
has not been performed.)
Continuous lighting time of
the backlight
Over 60 minutes
(Recommended)
“Over 240 min” indicates more
than 240 minutes has elapsed.
Luminance status
Stable: Luminance is stable.
(Recommended)
Unstable: Luminance is
unstable.
5MP
CURRENT STA T E
LUMINA N C E : 409
AMB LI G H T : 1 0 0.0
lx
COLO R : 7 500 K
( x=0.300 y=0. 315)
INPU T : D VI
CALI BRAT I ON S E T T I N G
CONF IG : 1
L U MINANCE : 410 / 0. 6
G A MMA : D I C O M GSD F
COLO R : 7 500 K
( x=0.299 y=0. 315)
CURRENT STATE
Gamma setting
5) Press the “BACK button.
