4 Design and Function
4.1 Enclosure
Fig. 5 Enclosure
1 Control cabinet door
2 Latch
3 Panel (removable)
The enclosure, when closed, serves various functions:
■ sound insulation
■ protection against contact with components
■ cooling air flow control
Safe and reliable operation is only assured with the enclosure closed.
Access doors are hinged to swing open and removable panels can be lifted off.
Latches are released by a key supplied with the machine.
4.2 Functional Description of the Machine
Functional description using an air-cooled machine as an example.
4 Design and Function
4.1 Enclosure
24
Service Manual Screw Compressor
ASD T Tri-Voltage 9_5721 06 USE

KAESER ASD T Series Specifications

General

Model	ASD T Series
Category	Compressor
Frequency	50/60 Hz
Drive System	Direct Drive
Cooling	Air-cooled
Type	Rotary Screw Compressor
Cooling System	Air-cooled
Control System	Sigma Control 2
Pressure	Up to 15 bar
Integrated Dryer	Yes
Voltage	400 V
Weight	Varies by model
Drive Motor	IE3 Premium Efficiency
