4. COMPONENTS OF
UPPERSTRUCTURE AND USAGE
4.1. Gooseneck Area
There is a control panel on the left side
of the gooseneck to control the hydraulic
components of the vehicle.
Location of the control panel
Pump start button
Hydraulic control levers
There is 1 step on the left side of the
gooseneck to make it easier to climb on
the gooseneck. To open the step, grasp
the upper part of the step and pull slightly
upwards. Then turn it on as in the pic-
ture. Fold and close the step after use.
Make sure the step is off while
driving. Otherwise, it may cau-
se serious damage, injury or
even death.
Step
There is a tool cabinet on the left front of
the gooseneck. In this tool cabinet;
• 1 x 3.5'' king pin (option),
• 1 minimess measuring hose,
• 1 steering system indicator lamps
assembly,
• 1 remote control system assembly,
• 3 meter interconnection cable: with
NATO socket (when NATO or Rema
socket option is selected),
• There is a rotating warning lamp
(option).
Toolbox
