37 / 84
2 Hz * Indicates that the angle sensor on the
fifth wheel is faulty. Continues until the
fault is fixed.
* 2 Hz Indicates that the angle sensor in the
steering hub is faulty. Continues until
the fault is fixed.
(*)(*)Lamp can be in any state (Continuous on / on intermittently / not on).
(><)The lamps flash in sequence relative to each other.
While the yellow lamp is on, the red lamp is not lit.
While the red lamp is on, the yellow lamp is not lit.
(<>)Lamps flash synchronously at the same time.
3.6.5. Remote Controller
It is the remote control of the steering
function of the trailer with the help of a
wireless controller. Wireless control; It
consists of 1 Receiver unit and wireless
controller.
Wireless controller and receiver
By connecting the wireless control re-
ceiver unit to the 13-pin steering sockets
on the front and rear of the trailer, the
steering function is controlled with the
wireless remote control.
Remote controller
Button 1 and 3 – Left/Right Turn:
The left button turns the wheels to the
right, and the right button turns the
wheels to the left. This is because the
wheels rotate in the opposite direction of
the truck's rotation.
Button 2 – Auto Alignment:
By pressing this button the Trailer is au-
tomatically aligned.
Button 4 – “ON” Start Button:
By pressing this button, the wireless con-
trol on / off operation is performed.
Button 5 – “SET” Button:
This button is used for the Angle Sensor
Calibration function on vehicles with Au-
to-Alignment System.
