Spare wheel holders
Possible squeezing, pinching
or cutting etc. when dealing
with the spare tire. There is a
risk of accident due to the
operation! The spare tire
could fall and injure the driver.
Be extremely careful when
dealing with the spare tire!
Driving with insufficiently se-
cured spare tire(s) may cause
traffic accidents.
For which tire the spare tire
holder is designed, only carry
that type of tire in the holder.
When the option is selected, the spare
wheel crane can be attached to the
spare wheel holder, which is located on
the top right of the gooseneck as stand-
ard. Thanks to this crane, it is easier to
remove and lower the spare wheel on
the gooseneck.
4.1.1. Gooseneck Separating and
connecting
4.1.1.1. Moving The Gooseneck
There are 2 hydraulic cylinders on the
back of the gooseneck. Thanks to these
cylinders, the gooseneck can be moved
up and down. Thus, when the platform
approaches the ground with the deflec-
tion formed in the pool when the vehicle
is loaded, the gooseneck is moved and
the pool is lifted up.
Hydraulic Cylinders
4.1.1.2. Gooseneck Separating and
connecting
4.1.1.2.1. Gooseneck Separating
The maneuvers mentioned be-
low must be done on absolu-
tely flat ground with a tow
truck suitable for Low-Loader.
The trailer must be mechani-
cally aligned.
1)Make electrical connections.
The locations of the electrical connections
2) By lowering the vehicle from the
gooseneck, set the pool on the supports
or on the ground. In order to lower the
gooseneck, hold down the pump start
button as in the picture, at the same time
bring the lever 3 down.
