Instructions for use ELECTROmatic TM and TMM/TMC
4 Installation | 4.1 Location
34 / 90
4 Installation
4.1 Location
WARNING
Installation of the device on a dental treatment unit.
Electrical shock or fire hazard.
▶ Mind the electrical cord of the power supply! Route all cords appropriately
such that they do not get squashed, clamped or have a chair rolling over
them.
▶ Before installation, note the instructions for use and installation instructions
of the treatment unit on which the device is to be installed.
See also:
2 2.3 Technical condition, Page 12
CAUTION
Damage to the dentist element.
Installations involving an intervention on the treatment unit might damage
components, which can interfere with the safe function and cause injury.
▶ Have installations involving an intervention on the treatment unit per-
formed by trained expert personnel only.
▶ Have the treatment unit subjected to a safety check after installation.
CAUTION
Power supply and cords/hoses are on the floor.
Slipping and tripping.
▶ Power supply and cord/hoses need to be set-up/routed appropriately such
that they are not on the floor.
Note
To completely disconnect the device from the mains, the mains plug must be
pulled. For this reason, the unit must be set-up appropriately such that the
mains plug and the electrical outlet are easily accessible.
Note
Use the power supply in dry environments exclusively. Make sure that the
power supply is protected from the ingress of liquids.
▶ Place the product in an easily accessible place and visible for diagnostic pur-
poses.
4.2 Installation positions
There is a wide range of installation options for the ELECTROmatic. This over-
view makes no claim of being comprehensive. If possible, the installation
should be done such that the dentist element is not modified and/or existing at-
tachment options on the dentist elements should be utilised.
The 4 basic installation positions on holders are described in the following.
▪ Installation position 1: Below a holder
▪ Installation position 2: On the side of a holder
▪ Installation position 3: On a holder or on the backside of a holder
