Instructions for use ELECTROmatic TM and TMM/TMC
3 Description of the product | 3.7 Symbols on product and rating plate
1)
pressure measured at the motor coupling using a pressure gauge Mat. no.
1.003.1050.
Speed
Speed range of the Motor KL 703 100 - 40,000 min
-1
(rpm)
Speed range of the
COMFORTdrive 200 XDR
20,000 - 200,000 min
-1
(rpm)
Motor torque
Torque of the Motor KL 703 max-
imum
3 Ncm
Torque of the Motor KL 703 min-
imum
0.15 Ncm
Maximum torque
COMFORTdrive 200 XDR
0.4 Ncm
Electrical ratings
Input voltage 36 V DC
Power 120 W
Motor cords
Cabling lengths,
depends on ordered version
1.75 m / 2.20 m (69" / 87")
3.7 Symbols on product and rating plate
The rating plates are affixed to the underside of the unit.
Accompanying documents
Follow the instructions for use
Follow the instructions for use
Follow the electronic instructions for use
HIBC Code
Certification
CE mark (Communauté Européenne)
29 / 90
