Instructions for use ELECTROmatic TM and TMM/TMC
3 Description of the product | 3.3 ELECTROmatic – Versions
3.3 ELECTROmatic – Versions
ELECTROmatic TMM/TMCELECTROmatic TM
7 7
7
ELECTROmatic Front and rear of the device
① Control panel ⑤ Motor hose connector:
- On the right, as seen from behind,
label on underside of the device
showing "M1" = connector with
ENDO function
- On the left, as seen from behind,
label on underside of the device
showing "M2" = connector without
ENDO function
② Control unit ⑥ 4-hole standard connector
③ Inspection window status LED ⑦ Water filter, replaceable
④ Power supply connector
