Instructions for use ELECTROmatic TM and TMM/TMC
4 Installation | 4.8 Connecting the ELECTROmatic
48 / 90
CAUTION
Damage to the dentist element.
Installations involving an intervention on the treatment unit might damage
components, which can interfere with the safe function and cause injury.
▶ Have installations involving an intervention on the treatment unit per-
formed by trained expert personnel only.
▶ Have the treatment unit subjected to a safety check after installation.
The following parts from the scope of delivery and the installations set are
needed:
▪ 1x Insert holder
▪ 1x Mounting bracket
▪ 1x Cover panel
▪ 4x + 2x screws M4x12 ④ with self-locking nuts ①
▪ 4x + 2x washers ②
▪ Optional: 4x spacer bolts, 35 mm ⑦
▪ Optional: 1x mounting plate
▪ 2x plastic screws ⑥
▶ Open the cabinet.
▶ Define the position of the control panel in the cabinet or on the wall and
draw a hole pattern for attachment. If possible, use existing screws or per-
forations as screw positions.
▶ Installation on a cabinet: Use 2 plastic screws to screw the control panel to
the cabinet.
▶ Installation on the wall: Use 2 screws ④ and washers ② to screw the angle
bracket with control panel to the wall and secure it with the nuts ①.
▶ Mount the control unit.
See also:
2 4.4 Installation position 1: Mount below a holder, Page 36
4.8 Connecting the ELECTROmatic
See also:
2 5.1.2 Connecting the ELECTROmatic, Page 49
2 5.1.5 Connect the power supply, Page 51
4.9 Check the installation
▶ Check if the fastening is secure.
▶ Perform the startup.
See also:
2 5 Startup, Page 49
