Instructions for use ELECTROmatic TM and TMM/TMC
6 Operation | 6.4 PREP mode
6.4 PREP mode
Operation general
If the display shows the "PREP" control element, preparation mode is active.
Activated values are shown with a blue background and can be changed.
Deactivated values are shown with a grey background.
▶ To change a value with a grey background, activate the value by touching
it.
▶ Once the value is activated, use the slider to set the value.
6.4.1 Changing the speed setting in PREP mode
The user can set 5 speed memories in Preparation mode. The speed memories
can be called up by pressing the corresponding control element on the left or
right side. The preset speed values, divided by 1000 min
-1
/rpm, are shown on
the left or right depending on the motor. The speeds of the clamped rotating
tools are displayed.
Speed display motor left
Speed display motor right
Speed display COMFORTdrive
right
The following factory settings a selected as defaults for the speed memories:
Speed memory INTRA LUX KL 703 LED
[min
-1
/rpm]
COMFORTdrive 200 XDR
[min
-1
/rpm]
1 100 20,000
2 1,000 40,000
3 5,000 60,000
4 20,000 100,000
5 40,000 200,000
The display shows the set speed of the rotating clamped tools (speed min
-1
/
rpm x 1,000)
▶ Touch the slider and pull it to the right or left to increase or reduce the
speed.
ð The display shows the set speed of the clamped rotating tool.
57 / 90
