Instructions for use ELECTROmatic TM and TMM/TMC
4 Installation | 4.3 Prepare installation
36 / 90
4.3 Prepare installation
Insert holder
Mounting plate
Mounting bracket
Cover panel
ELECTROmatic installation set (Mat. no. 1.012.1883)
▶ Keep the installation set handy.
▶ For the parts from the scope of delivery required for each installation, see
list in the respective installation chapter.
▶ If needed, keep a suitable tool for shortening the mounting plate handy.
Note
If a larger gap needs to be bridged for installation, larger spacer bolts ⑦ from
commercial electronics supplies can be used.
▶ Connect the motor hose(s) to the ELECTROmatic.
▶ Connect motor(s) to motor hose(s).
See also:
2 5.1.3 Connect the motor, Page 50
▶ Check to make sure that the motor is seated firmly in the holder of the
dental unit.
4.4 Installation position 1: Mount below a holder
Below a holder with insert holder
To Next Page
