192
Parameter List Reference
Para. Name E R Res. Lower
Limit
Upper
Limit
Default Unit
LP.1 One Floor Positioning E R/W 1 0:off 2 : P onE 0 -
LP.2 Maximum Slowdown Distance R 0.1 0.0 200.0 0.0 inches
LP.3 Slowdown Distance E R/W 0.1 0.0 200.0 0.0 inches
LP.4 Correction Distance E R/W 0.1 0.0 50.0 0.0 inches
LP.12 Current Position R 0.1 0.0 9999.9 0.0 inches
LP.21 Scaling Increments High E R/W 1 0 9999 0 -
LP.22 Scaling Increments Low E R/W 1 0 9999 0 -
LP.23 Scaling Distance E R/W 0.1 0.0 999.9 0 inches
Para. Name E R/
W
Res. Lower
Limit
Upper
Limit
Default Unit
US.00 Operator application R 1 - - - -
US.01 Password E R/W 1 0 9999 660 -
US.03 Default all LF parameters E R/W 1 1 1 0:bdPAS -
US.04 Load con guration E R/W 1 1 1 0:bdPAS -
US.10 Select Con guration E R/W 1 0 4 1 text
US.16 E.OL2 function E R/W 1 0 255 80 -
US.17 Synthetic Pre - Torque Brake Release
Timer
E R/W 0.01 0.00 32.00 0.40 sec
US.18 Synthetic Pre - Torque Hold On Timer E R/W 0.01 0.00 32.00 0.10 sec
US.20 max speed for max KI E R/W 1 0 1600 8 fpm
US.21 speed for min KI E R/W 1 0 1600 24 fpm
US.22 Speed Dependent KP Gain E R/W 1 0 1 0 -
US.23 Min KP Gain at High Speed E R/W 1 0 50396 1000 -
US.24 KD speed gain E R/W 1 0 5000 0 -
US.25 Phase Current Check E R/W 1 0 4 3 -
US.28 Analog Input Noise Clamp E R/W 0.1 -2.5 2.5 0.1 %
US.29 HSP5 Watchdog Time E R/W 0.01 0.0 = oFF 10.00 1.00 Sec
US.33 EdOH function E R/W 1 0 = off 1 = on 0 -
US.34 Analog Pattern Gain E R/W 0.01 0.01 20.00 1.00 -
US.35 Reference Splitting E R/W 1 0 (off) 200 0 mSec
US.36 External Serial Com Baud Rate E R/W 1 0 6 5 -
US.37 Test Function E R/W 1 0 (off) 1 0 -
