Keba KeContact Series User Manual

Load management program
144 / 156
6.9.9.2 Configure Central system interface - Communication
This screen is for the configuration of the communication between the charge point and the Central system.
Configure OCPP Interface - Central system interface Communication
Identification
Interface name:
Identification name of the interface.
Addressing
Use TLS?
Indicates whether the OCPP communication shall use HTTPS (checkbox
checked) or HTTP (unchecked).
Address central system:
The URL of the host (with the port) to be used for OCPP communication
with that host.

Keba KeContact Series Specifications

General

Charging power	Up to 22 kW
Protection class	IP54
Frequency	50/60 Hz
Operating Temperature	-25°C to +55°C
Rated current	32 A
Connection type	Type 2 socket
Communication	Ethernet
Residual current monitoring	Type A
Output Current	Up to 32 A
