Keithley 2010 Service Manual

Resistance calibration
Follow these steps for resistance calibration:
1. Set the calibrator to the resistance mode, and turn on external sensing.
NOTE Use external sense (4-wire
Ω ) when calibrating all resistance ranges. Be sure that the
calibrator external sense mode is turned on,
2. Perform the calibration steps summarized in Table 2-9. For each step:
• Set the calibrator to the indicated resistance, and make sure the unit is in operate.
(Use the recommended resistance or the closest available value.)
• Send the indicated programming command. (Change the command parameter if you
are using a different calibration resistance than that shown.)
• Wait until the Model 2010 completes each step before continuing.
Table 2-9
Resistance calibration programming steps
Calibration
step
Calibrator
resistance Calibration command* Parameter range
10Ω
1kΩ
10kΩ
100kΩ
1MΩ
10Ω
1kΩ
10kΩ
100kΩ
1MΩ
:CAL:PROT:DC:STEP6 10
:CAL:PROT:DC:STEP7 1E3
:CAL:PROT:DC:STEP8 10E3
:CAL:PROT:DC:STEP9 100E3
:CAL:PROT:DC:STEP10 1E6
9 to 11
900 to 1.1E3
9E3 to 11E3
90E3 to 110E3
900E3 to 1.1E6
* Use exact calibrator resistance value for parameter.
2-16 Calibration
