Keithley 2010 Service Manual

DC calibration commands
The :DC commands perform calibration of the DCV, DCI, and ohms
functions.Table B-2 summarizes these calibration commands along with
parameter limits.
:STEP1 (:CALibration:PROTected:DC:STEP1)
Purpose To perform front terminal short-circuit calibration.
Format :cal:prot:dc:step1
Description :STEP1 performs the short-circuit calibration step in the comprehensive
calibration procedure. Connect a low-thermal short (Model 8610) to the front
panel input jacks before sending this command.
Example :CAL:PROT:DC:STEP1 Perform short-circuit calibration.
Table B-2
DC calibration commands
Command Description
Parameter
limits
:CALibration
:PROTected
:DC
:STEP1
:STEP2
:STEP3 <NRf>
:STEP4 <NRf>
:STEP5 <NRf>
:STEP6 <NRf>
:STEP7 <NRf>
:STEP8 <NRf>
:STEP9 <NRf>
:STEP10 <NRf>
:STEP11 <NRf>
:STEP12 <NRf>
:STEP13 <NRf>
Front terminal short circuit.
Open circuit.
10V DC calibration step.
-10V DC calibration step.
100V DC calibration step.
10Ω 4-wire calibration step.
1kΩ 4-wire calibration step.
10kΩ 4-wire calibration step.
100kΩ 4-wire calibration step.
1MΩ 4-wire calibration step.
10mA DC calibration step.
100mA DC calibration step.
1A DC calibration step.
9 to 11
-9 to -11
90 to 110
9 to 11
900 to 1.1E3
9E3 to 11E3
90E3 to 110E3
900E3 to 1.1E6
9E-3 to 11E-3
90E-3 to 110E-3
0.9 to 1.1
B-8 Calibration Command Reference

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
