Keithley 2010 Service Manual

DC current calibration
After the 1MΩ resistance point has been calibrated, follow these steps for DC current
calibration:
1. Connect the calibrator to the AMPS and INPUT LO terminals of the Model 2010 as
shown in Figure 2-3.
2. Perform the calibration steps listed in Table 2-10. For each step:
• Set the calibrator to the indicated current, and make sure the unit is in operate. (Use
the recommended current if possible.)
• Send the indicated programming command. (Change the current parameter if you are
using a different calibration current.)
• Wait until the Model 2010 completes each step before continuing.
NOTE If you are performing DC-only calibration, proceed to Programming calibration
dates.
Table 2-10
DC current calibration programming steps
Calibration
step
Calibrator
current Calibration command* Parameter range
10mA
100mA
1A
10.00000mA
100.00000mA
1.000000A
:CAL:PROT:DC:STEP11 10E-3
:CAL:PROT:DC:STEP12 100E-3
:CAL:PROT:DC:STEP13 1
9E-3 to 11E-3
90E-3 to 110E-3
0.9 to 1.1
* Change parameter if using different current.
Calibration 2-17

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
