Recommended equipment
Table 2-1 lists the recommended equipment you need for comprehensive, DC only, and AC
only calibration procedures. You can use alternate equipment, such as a DC transfer standard and
characterized resistors, as long as that equipment has specifications at least as good as those
listed in the table.
Aborting calibration
You can abort the front panel calibration process at any time by pressing EXIT. The
instrument will then ask you to confirm your decision to abort with the following message:
ABORT CAL?
Press EXIT to abort calibration at this point, or press any other key to return to the calibration
process.
NOTE The Model 2010 will not respond to any remote programming commands while the
ABORT CAL? message is displayed.
Table 2-1
Recommended equipment for comprehensive, DC-only, or AC-only calibration
Fluke 5700A calibrator:
DC voltage
AC voltage
(1kHz, 50kHz)* DC current
AC current
(1kHz) Resistance
±10V:±5ppm
100V:±7ppm
10mV:±710ppm
100mV:±200ppm
1.0V:±82ppm
10V:±82ppm
100V:±90ppm
700V:±85ppm
10mA:±60ppm
100mA:±70ppm
1A:±110ppm
100mA:±190ppm
1A:±690ppm
2A:±670ppm
10Ω:±28ppm
1kΩ:±12ppm
10kΩ:±11ppm
100kΩ:±13ppm
1MΩ:±18ppm
Keithley 8610 Low-thermal shorting plug
* 1kHz specifications. 10mV and 700V points require 1kHz only. All calibrator specifications are
90-day, 23°C ±5°C specifications and indicate total absolute uncertainty at specified output.
Calibration 2-5
