Keithley 2010 Service Manual

Table 6-4
Mechanical parts list
Description Keithley part no.
BANANA JACK, PUSH-IN, BLACK
BANANA JACK, PUSH-IN, RED
BEZEL, REAR
CARD GUIDE/SHIELD
CHASSIS
CHASSIS ASSEMBLY
CHASSIS ASSEMBLY
CONTACT, CURRENT INPUT
COVER
COVER PANEL, SCANNER
DISPLAY LENS
FOOT
FOOT, EXTRUDED
FOOT, RUBBER
FRONT PANEL
FRONT PANEL OVERLAY
FRONT PANEL PRINTED
FRONT/REAR SWITCH ROD
FUSE HOLDER
FUSE 0.25A
FUSE, 3A, 250
JACK, CURRENT INPUT
JACK, CURRENT INPUT
LINE MODULE
MOTHERBOARD SHIELD
MOUNTING EAR, LEFT
MOUNTING EAR, RIGHT
POWER ROD
REAR PANEL
SWITCHPAD
TRANSFORMER
WIRE, 16GA GRN/YEL
BJ-13-0
BJ-13-2
428-303D
2000-311A
2000-305
2000-309F
2010-MECH-6
2001-313C
2000-307C
2001-372A
2010-304A
428-319A
FE-22A
FE-6
2001-302G
2000-303A
2010-301A
2001-322A
FH-35-1
FU-96-4
FU-99-1
2001-312D
V-2001-312D
PM-1-1B
2000-306B
428-338B
428-328E
2001-320A
2000-308
2000-310A
TR-299B
SC-73-5
Replaceable Parts 6-11

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
