Remote trigger example
Table 8-2 summarizes the command sequence for basic trigger operation. These commands set
up Model 6482 triggering as follows:
• Arm layer source: Bus
• Arm layer count: 2
• Trigger layer delay: 0.1 s
• Trigger layer count: 10
• Trigger layer output events: Source and sense
• Trigger layer trigger link output line: 1
After the instrument is set up, :INIT is sent to take the instrument out of the idle state. *TRG is sent
to trigger the instrument, after which it cycles 10 times through the trigger layer. A second *TRG is
required to trigger the instrument the second time, and it then completes the second cycle through
the trigger layer.
NOTE You must allow sufficient time between the first and second *TRG commands, or the
second trigger will be ignored.
Table 8-2
Remote triggering example
Command Description
*RST
:SOUR1:VOLT 10
:ARM:SOUR BUS
:ARM:COUN 2
:TRIG:DEL 0.1
:TRIG:COUN 10
:TRIG:OUTP SOUR,SENS
:TRIG:OLIN 1
:OUTP1 ON
:INIT
*TRG
*TRG
:OUTP1 OFF
:FETC?
Restore GPIB defaults.
Source 10 V on channel 1.
Select bus arm layer source (*TRG command).
Arm layer count = 2.
0.1 s trigger layer delay.
Trigger layer count = 10.
Source, sense output trigger events.
Trigger output line = #1.
Turn on channel 1 output.
Take instrument out of the idle state.
Trigger first sequence.
Trigger second sequence.
Turn off output 1.
Request readings.
