Section 16: SCPI Command Reference Model 6482 Dual-Channel Picoammeter / Voltage Source Reference Manual
Calculate subsystems
There are a total of eight CALCulate subsystems:
• CALC1: Channel 1 math
• CALC2: Channel 2 math
• CALC3: Channel 1 relative offset
• CALC4: Channel 2 relative offset
•CALC5: Ratio
• CALC6: Delta
• CALC7: Limit tests
• CALC8: Buffer statistics
The commands in these subsystems are summarized in Table 16-1.
NOTE See Appendix B for a detailed explanation on how data flows through the various CALC
operation blocks of the Model 6482. It clarifies the type of readings that are acquired by
the various commands to read data.
Command Description
Default
parameter SCPI
:TRIGger
[:SEQuence[1]]
[:TCONfigure]
:DIRection <name>
:DIRection
[:ASYNchronous]
:ILINe <n>
:ILINe?
:INPut <event list>
:INPut?
:OLINe <n>
:OLINe?
:OUTPut <event list>
:OUTPut?
Path to program Trigger Layer (continued):
Enable (SOURce) or disable (ACCeptor) bypass.
Query state of bypass.
Configure output triggers:
Select input trigger line (1, 2, 3, 4, 5, or 6).
Query input trigger line.
Enable input event detectors (SOURce, DELay,
SENSe, or NONE).
Query enabled input event detectors.
Select output trigger line (1, 2, 3, 4, 5, or 6).
Query output trigger line.
Output trigger after SOURce, DELay, SENSe
or not (NONE) at all.
Query when output trigger is going to occur.
1
NONE
2
NONE
9
9
9
9
Table 16-10 (cont.)
TRIGger command summary
