Remote filter programming
Filter commands
Table 4-6 summarizes filter commands. See Section 16 for more details.
* Because filter commands are global, :SENSe[1] (channel 1) commands also affect equivalent :SENSe2 (channel 2) settings.
Table 4-6
Filter commands
Commands* Description
Average filter:
[:SENSe[1]]:AVERage:COUNt <n>
[:SENSe[1]]:AVERage:TCONtrol <name>
[:SENSe[1]]:AVERage[:STATe] <state>
[:SENSe[1]]:AVERage:ADVanced:NTOLerance <NRf>
[:SENSe[1]]:AVERage:ADVanced[:STATe] <state>
:SENSe2:AVERage:COUNt <n>
:SENSe2:AVERage:TCONtrol <name>
:SENSe2:AVERage[:STATe] <state>
:SENSe2:AVERage:ADVanced:NTOLerance <NRf>
:SENSe2:AVERage:ADVanced[:STATe] <state>
Median filter:
[:SENSe[1]]:MEDian:RANK <NRf>
[:SENSe[1]]:MEDian[:STATe] <state>
:SENSe2:MEDian:RANK <NRf>
:SENSe2:MEDian[:STATe] <state>
Set Channel 1 average filter count (n = count, 1 to 100).
Select Channel 1 filter type (name = MOVing or REPeat).
Enable or disable Channel 1 filter (state = ON or OFF).
Set Channel 1 advanced filter noise window in
percentage (NRf = noise window, 0 to 105).
Enable or disable Channel 1 advanced filter (state = ON
or OFF).
Set Channel 2 average filter count (n = count, 1 to 100).
Select Channel 2 filter type (name = MOVing or REPeat).
Enable or disable Channel 2 filter (state = ON or OFF).
Set Channel 2 advanced filter noise window in
percentage (NRf = noise window, 0 to 105).
Enable or disable Channel 2 advanced filter (state = ON
or OFF).
Set Channel 1 median filter rank (NRf = rank, 0 to 5).
Enable or disable Channel 1 median filter (state = ON or
OFF).
Set Channel 2 median filter rank (NRf = rank, 0 to 5).
Enable or disable Channel 2 median filter (state = ON or
OFF).
