4-12 Return to Section Topics 6482-901-01 Rev. A / August 2012
Section 4: Range, Digits, Speed, and Filters Model 6482 Dual-Channel Picoammeter / Voltage Source Reference Manual
Filter programming example
Table 4-7 summarizes the command sequence to program channel 1 filter attributes as follows:
• Average filter: Off
• Median filter state: On
• Median filter rank: 5
• Average filter state: On
• Average filter type: Moving
• Average filter count: 20
• Advanced filter state: On
• Advance filter tolerance: 10 percent
Table 4-7
Filter programming example
Command Description
:MED:RANK 5
:MED ON
:AVER:TCON MOV
:AVER:COUN 20
:AVER ON
:AVER:ADV OFF
:AVER:ADV:NTOL 10
Set median rank to 5.
Enable median filter.
Select moving filter type.
Set moving count to 20.
Enable average filter.
Disable advanced filter.
Set filter tolerance to 10%.
