6482-901-01 Rev. A / August 2012 Return to Section Topics 16-3
Model 6482 Dual-Channel Picoammeter / Voltage Source Reference Manual Section 16: SCPI Command Reference
Table 16-1
CALCulate command summary
Command Description
Default
parameter SCPI
:CALCulate[1]
:FORMat <name>
:KMATh
:MBFactor <n>
:MBFactor?
:MMFactor <n>
:MMFactor?
:MUNits “<string>”
:MUNits?
:STATe <b>
:STATe?
:DATA
:LATest?
:DATA?
:CALCulate2
:FORMat <name>
:KMATh
:MBFactor <n>
:MBFactor?
:MMFactor <n>
:MMFactor?
:MUNits “<string>”
:MUNits?
:STATe <b>
:STATe?
:DATA
:LATest?
:DATA?
:CALCulate3
:FEED <name>
:FEED?
:NULL
:OFFSet <NRf>
:OFFSet?
:STATe <b>
:STATe?
:ACQuire
:DATA?
:CALCulate4
:FEED <name>
:FEED?
:NULL
:OFFSet <NRf>
:OFFSet?
:STATe <b>
:STATe?
:ACQuire
:DATA?
Subsystem to control CALC1 (channel 1) math:
Select math format (MXB[1], COND[1],
POWER[1], or RES[1]).
Configure MX + B parameters.
Set B parameter (-9.99999e20 to 9.99999e20).
Query B parameter.
Set M parameter (-9.99999e20 to 9.99999e20).
Query M parameter.
Set MX + B units (1 to 3-character ASCII string).
Query M parameter.
Enable or disable CALC1 math.
Query state of math.
Path to CALC1 data.
Return only most recent math result.
Read result of math.
Subsystem to control CALC2 (channel 2) math:
Select math format (MXB2, COND2, POWER2,
or RES2).
Configure MX + B parameters.
Set B parameter (-9.99999e20 to 9.99999e20).
Query B parameter.
Set M parameter (-9.99999e20 to 9.99999e20).
Query M parameter.
Set MX + B units (1 to 3-character ASCII string).
Query M parameter.
Enable or disable CALC2 math.
Query state of math.
Path to CALC2 data.
Return only most recent math result.
Read result of math.
Subsystem to control CALC3 (channel 1 RELATIVE
OFFSET):
Select input path (SENSe[1] or CALCulate[1]).
Query CALC3 feed.
Path to configure and control REL:
Specify REL value (-9.999999e20 to 9.999999e20).
Query REL value.
Enable or disable REL.
Query state of REL.
Automatically acquire REL value.
Read CALC3 data.
Subsystem to control CALC4 (channel 2 REL):
Select input path (SENSe2 or CALCulate2).
Query CALC4 feed.
Path to configure and control REL:
Specify REL value (-9.999999e20 to 9.999999e20).
Query REL value.
Enable or disable REL.
Query state of REL.
Automatically acquire REL value.
Read CALC4 data.
MXB[1]
0
1
“MXB”
OFF
MXB2
0
1
“MXB”
OFF
SENS1
0
OFF
SENS2
0
OFF
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
