Table 1-4
Measurement configuration menus
Configuration menu item Description
CONFIG > MSR1
CONFIG MSR1 BUTTON
I
I/V
V/I
MX + B_UNIT
P
CONFIG > MSR2
CONFIG MSR2 BUTTON
I
I/V
V/I
MX + B_UNIT
P
CONFIG > RATIO
CONFIG RATIO BUTTON
MSR1/MSR2
MSR2/MSR1
CONFIG > DELTA
CONFIG DELTA BUTTON
MSR1-MSR2
MSR2-MSR1
Configure channel 1 measurement.
Current measurement.
Conductance (I/V) measurement.
Resistance (V/I) measurement.
MX + B measurement, program M and B values.
Electrical power (V × I) measurement.
Configure channel 2 measurement.
Current measurement.
Conductance (I/V) measurement.
Resistance (V/I) measurement.
MX + B measurement, program M and B values.
Electrical power (V × I) measurement.
Configure ratio function.
MSR1/MSR2 function.
MSR2/MSR1 function.
Configure delta function.
MSR1-MSR2 function.
MSR2-MSR1 function.
Table 1-5
Source configuration menus
Configuration menu item Description
CONFIG > SRC1
CONFIG SRC1
DELAY
AUTO-DELAY
DISABLE
ENABLE
GND-CONNECT
DISABLE
ENABLE
CONFIG > SRC2
CONFIG SRC2
DELAY
AUTO-DELAY
DISABLE
ENABLE
GND-CONNECT
DISABLE
ENABLE
Configure voltage source.
Configure delay and ground connect mode.
Set source delay (0 to 9999.998 s).
Control source autodelay.
Disable autodelay.
Enable autodelay (delay depends on current range).
Control ground connect mode.
Disable ground connect mode.
Enable ground connect mode.
Configure voltage source.
Configure delay and ground connect mode.
Set source delay (0 to 9999.998 s).
Control source autodelay.
Disable autodelay.
Enable autodelay (delay depends on current range).
Control ground connect mode.
Disable ground connect mode.
Enable ground connect mode.
