Installation
31
3.1.6 Mechanical Installation of the electronics (remote versions)
TCE80xx-W
The wall mount unit is to be mounted on the wall with 2 screws with 5mm diameter, about 40mm apart. For exact
dimensions refer to chapter 7.3.4
TCE80xx-E
The wall mount unit is to be mounted on the wall with 2 to 4 screws with 5mm diameter, 45mm apart. For exact
dimensions refer to chapter 7.3.4
If the mounting point should be located behind the TCE80xx instead beside, unscrew the 4 screws fixing the
bracket to the housing, fix the bracket to the wall and reaffix the housing to the bracket.
TCE80xx-L, TCE800-S
The housing requires an opening in the panel of 92mm x 92mm (TCE80xx-S) or138mm x 92mm (TCE80xx-L) at a
maximum panel thickness of 2mm.
Push the TCE80xx into the opening. The springs will fix the unit automatically.
For removing the TCE80xx press the springs towards the housing via a screwdriver.
WARNING!
For mounting the unit in hazardous areas refer to chapter 3.3
