KEM TRICOR TCE80 -E Series User Manual

Service and Maintenance
76
6.4.1 Temperature Calibration
For calibrating the temperature reading of the TCE8000, the medium temperature must be well known.
Before starting the calibration make sure that the temperature reading has been stable for several
minutes for making sure that the medium temperature and the temperature of the temperature sensor
are the same.
CALIBRATION MENU
METER VAR.
UP DOWN EXIT
P 
SET TEMP IN °C
25.0
RIGHT UP EXIT
Use the keys “RIGHT” and “UP” to set the actual medium temperature and confirm with “P” or skip
with “E”.
The display returns to the CALIBRATION menu.
6.4.2 Air Density Calibration
NOTE
Make sure that the temperature reading is calibrated before starting the air calibration.
The low end calibration of the density measurement is normally done with empty tubes (filled with air).
In the automatic mode the unit performs an automatic calibration, assuming that the tubes are filled
with normal air.
In the manual mode the three parameters temperature, tube frequency and reference density can be
altered individually. This is necessary if the air calibration is performed with a gas with a density
different than air. In that case make first the automatic calibration and then override in the manual
calibration the density value by the density of the medium used for calibration.
Before starting an automatic calibration, make sure that the TCM is completely empty as any drop of a
liquid inside will spoil the calibration result.
CALIBRATION MENU
AIR CALIB.
UP DOWN EXIT
P 
AIR CALIBRATION MENU
AUTOMATIC
UP DOWN EXIT
Use the keys “UP” and “DOWN” to select the mode and confirm with “P” or skip with “EXIT”.
AUTOMATIC mode
AIR CALIBRATION MENU
AUTOMATIC
UP DOWN EXIT
P 
WARNING TUBES
HAVE TO BE FILLED
WITH AIR!!
. OK
Confirm with “OK”. The display shows
