Getting Started

2.3 Pin Assignments

2.3.1 Compact or wall mount version standard housing

Fig. 8: Electrical terminals TCE80xx-W and compact version

1 = Terminal screw for protective ground

2 = Switch for terminating resistor for the RS485 interface

3 = Terminal block for interface (RS485 and / or FF)

4 = Terminal block power supply

5 = Terminal block for I/O signals
