4.5.5 SETUP Menu
In the SETUP menu all settings can be made to adapt the meter to the individual requirements.
Select in the main menu
MAIN MENU
SETUP
UP DOWN EXIT
Press “P”. The display shows
ENTER CODE
2206
LEFT UP EXIT
Change the indicated number with “LEFT” and “UP” to 2207 and confirm with “P”.
If a wrong code is entered, the display shows “ERROR” for about 2s and then asks for a new input.
When the correct code is entered the display shows:
SETUP MENU
PARAMETER
UP DOWN EXIT
The following submenus are available:
PARAMETER:
METER MODE Selecting mass or volume meter mode
FLOW FILTER Setting the filter time constant
CUT OFF Setting the cutoff value
STEP RESP: Adjusting the settings for fast changing flow
RESET KEY Enable / disable the key “Reset”
FLOW-DIREC Setting up the unit for reverse flow
K-FACTOR Fine scaling the meter
FAULT TIME Setting the error response time
LANGUAGE Selecting the display language
IN/OUTPUTS:
FREQ OUT Configuring the frequency output
CTRL OUT Configuring the control output
ANALOG OUT Configuring the analog output
CTRL IN Configuring the control input
INTERFACE Configuring the interface
DATA CONFIG:
SAVE DATA Saving the actual settings as backup
RECALL DATA recalling the last settings from the backup
RESET TOTAL:
Resets the total count to zero.
Use the keys “UP” and “DOWN” to select the desired submenu and confirm with “P” or skip with “E”.
