7.3 Technical Data
7.3.1 Technical Data TCM Transducer
TCM0325 TCM0650 TCM1550 TCM3100 TCM5500 TCM7900 TCM28k TCM65k
Max. flow (kg/h) 300 600 1500 3000 5500 7900 28 000 65 000
Min. flow (kg/h) 3 6 15 30 55 79 280 650
Max. flow (lb/min) 11.0 22.0 55.0 110 203 291 1030 2390
Min. flow (lb/min) 0.11 0.22 0.55 1.10 2.03 2.91 10.3 23.9
Basic Accuracy (% of flow) 0.1
Zero Stability (% of f. s.) 0.01
Zero Drift (% f.s. per °C) 0.001
Repeatability (% of flow) 0.1
Density meas. range 0 - 4500 kg/m³
Density accuracy ±0.002 kg/ltr.
Temperature accuracy ±1°C ±0.5% of reading
Process and Ambient
Process connections female thread 1/2"
adaptors for flanges, diary and tri-clamp
flanges EN1092, ANSI B16.5, DIN2512
Max. pressure 200 bar 350 bar 100 bar
Max. pressure (Option) 350 bar
Pressure Drop at max. flow
H
2
0
see diagram
Operating Density range 500 - 2500 kg/m³
Process temperature -20 … +100°C (standard), -100 ... +150°C (upon request)
Ambient temperature -20 ... +70°C
Storage temperature -40 ... +100°C
El. connections remote screw type terminals
El. connections compact. none (internally connected to the electronics)
Ingress Protection IP67
General
Tube arrangement 2 serial 2 parallel 2 serial 2 parallel 2 parallel 2 parallel 2 parallel 2 parallel
Tube inner diameter 4mm 4mm 8mm 8mm 7mm 9mm 16mm 28mm
Tube material stainless steel DIN 1.4571
Housing material stainless steel DIN 1.4571
Dimensions see drawings
