Getting Started
20
2.3.2 TCE80xx-E and wall mount version
Fig. 9: Electrical terminals TCE80xx-E-*-Ex and compact version
1 = Terminal screw for protective ground
2 = Blind cover for cable opening (various numbers and positions)
3 = Cable gland (various numbers and positions)
4 = Terminal block for digital I/O signals (U
M
= 250V DC)
5 = Terminal block power supply (U
M
= 250V DC)
6 = Terminal block for Interface (U
M
= 30V DC)
7 = Terminal block for analog I/O signals (U
M
= 30V DC)
4
7
6
5
1
3
3
2
2
1
