Manual Operation
42
***……. WARNING …….***
NO ACTUAL RAM BACKUP
SEE MANUAL
OK
If no key is pressed the warning will disappear automatically after 10 seconds.
For further information refer to chapter 4.5.8.
Now the TCE8000 switches to the measuring mode, displaying the default screen:
0.000
RATE
0.00
TOTAL
The green LED “OK” flashes with a 1 second period. In case of an error the red LED “ERR” flashes.
In manual control the TCE is menu driven and provides 2 operational modes, the “Measuring Mode” and the
“Control Mode”.
In the measuring mode the display shows the preselected measured values and all 4 pushbuttons have the
function printed on them. The switch over between the different measuring displays and the error display can be
made at any time without interrupting the measurements.
In the control mode the 3 pushbuttons below the display have varying functions. The actual function is indicated in
the display, just above the pushbutton.
In the control menu all necessary settings can be made.
The control menu contains the 5 submenus “ZERO OFFSET”, “DISPLAY”, “SETUP”, “I/O-TEST” and “SERVICE”.
For protecting the unit against unintentional changes by unauthorized personnel, the menus “ZERO OFFSET”,
“SETUP” and “I/O-TEST” are protected by a user password and the menu “SERVICE” by a service password.
For the description of the control menu see chapter 4.5.
4.1.1 Using the magnet
In hazardous, wet and dusty areas the display cover must not be opened to operate the pushbuttons.
Beside every pushbutton there is a hall sensor which can be operated via the magnet attached to the housing.
For operating the keys hold the magnet to the glass.
The best positions for operating the keys are:
Key position
P right edge of the yellow area
Reset left edge of the yellow area
Display lower edge of the yellow area
Info right edge of the yellow area
4.2 Setup guidelines
Ex factory the Tricor mass flow meter come with an setup optimized for normal applications. In more than 90% of
the applications no further optimization except a regular offset adjustment is required.
The different possibilities for optimizing the settings are described below.
To Next Page
