7.3.3 Technical Data TCE 8000 Transmitter
General
Display: Graphic, 132 x 32 dot
Supply voltage: 24 VDC, ± 20%
Programming: via front keyboard
Interface: RS 485, option HART or Foundation Fieldbus
EMC: according to EN 61000-6-4 and EN 61000-6-2
Power consumption: max. 4 W
Exd housing:
Dimensions: see drawing
Connections: internal cage clamp terminals
via cable gland
Material: aluminum diecast
Protection class IP 65
Weight: approx. 2 kg
Temperature: operating:- 20 up to 70°C
storage and transport: -40 up to 80°C
Panel-mounted housing:
Dimensions: 96 x 144 x 100mm (h * w * d)
Connections: rear cage clamp terminals
Material: Noryl
Protection class: front: IP 60, rear: IP 30
Weight: approx. 500g
Temperature: operation: 0 to 60°C
storage and transport: -20 up to 70°C
