87
Analog Outputs
Two current outputs: 4-20 mA passive, two-wire, isolated
Resolution: 14 bit
Linearity: ± 0.05% of full scale
Temperature drift: 0.05% per 10K
Load: < 620 (at 24V supply)
Output value: flow rate, job total, density or temperature
Pulse Output
Frequency range: 0.5 -10,000 Hz
Output signal: active push pull output of flow rate and / or cycle output
Digital I/O
Status output type push pull
Low / high level 1V / 23V @ 24Vsupply, 10k load
Allowed load current 20mA max.
Output signal Programmable
Control input type Active high
Threshold voltage 6.5V
Input current 0.1mA @ 6.5V, 0.2mA @ 24V Vin
Input signal Programmable
