Service and Maintenance
75
6.4 Calibration
In the calibration menu the flow, density and temperature measurement of the TCE8000 can be
calibrated.
Press “P” for about 3 seconds
The display shows:
MAIN MENU
ZERO OFFSET
UP DOWN EXIT
Use the key “UP” or “DOWN” to select
MAIN MENU
SERVICE
UP DOWN EXIT
Press “P”. The display shows
ENTER CODE
2206
LEFT UP EXIT
Change the indicated number with “LEFT” and “UP” to 2208 and confirm with “P”.
If a wrong code is entered, the display shows “ERROR” for about 2s and then asks for a new input.
When the correct code is entered the display shows:
SERVICE MENU
CALIBRATION
UP DOWN EXIT
Press “P”. The display shows
CALIBRATION MENU
METER VAR.
UP DOWN EXIT
The following submenus are available:
TEMP CALIB. Calibrating the temperature measurement
AIR CALIB. Calibrating the density measurement at low density
WATER CALIB. Calibrating the density measurement at high density
METER VAR. Calibrating the flow measurement
