Manual Operation
67
4.5.10 I/O-TEST Menu
In the I/O-TEST menu all inputs and outputs can be tested.
Select in the main menu
MAIN MENU
I/O-TEST
UP DOWN EXIT
Press “P”. The display shows
ENTER CODE
2206
LEFT UP EXIT
Change the indicated number with “LEFT” and “UP” to 2207 and confirm with “P”.
If a wrong code is entered, the display shows “ERROR” for about 2s and then asks for a new input.
When the correct code is entered the display shows:
I/O-TEST MENU
FREQ OUT
UP DOWN EXIT
The following submenus are available:
FREQ OUT A freely settable frequency can be applied to the output
CTRL OUT The output level can be set
ANALOG OUT A freely settable current can be applied to the outputs
CTRL IN The current level at the input is indicated
When the I/O-TEST menu is left, all outputs return to normal operation.
4.5.10.1 FREQ OUT menu
In the submenu “FREQ OUT” a freely settable frequency between 1Hz and 9999Hz can be applied to the output.
I/O-TEST MENU
FREQ OUT
UP DOWN EXIT
P 
ENTER FREQUENCY
9.000 HZ
RIGHT UP EXIT
Use the keys “RIGHT” and “UP” to select the desired value and confirm with “P” or skip with “EXIT”.
If “P” was pressed the frequency is applied to the output and the display shows
ENTER NEW VALUE?
YES EXIT
Press “YES” to enter a new value or “EXIT” to leave the menu.
