Service and Maintenance
77
DO YOU WANT TO
PROCEED CALIBRATION?
YES NO
Start the calibration with “YES” or skip with “NO”.
When “YES” was pressed, the display shows
AIR-TEMP: 23.0°C
FREQUENCY: 141.5 Hz
DENSITY: 1.4 G/L
. OK
Confirm with “OK”. The display returns to the AIR CALIBRATION menu.
MANUAL MODE
AIR CALIBRATION MENU
MANUAL
UP DOWN EXIT
P
ENTER AIR TEMP:
23.0 °C
RIGHT UP EXIT
Use the keys “RIGHT” and “UP” to set the reference temperature and confirm with “P” or skip with
“EXIT”. The display shows
ENTER AIR FREQ:
141.52 Hz
RIGHT UP EXIT
This value must only be entered, if you have the data from a calibration sheet of the KCM. Skip with
“EXIT”. The display shows
ENTER AIR DENSITY:
1.407 G/L
RIGHT UP EXIT
Use the keys “RIGHT” and “UP” to set the reference density and confirm with “P” or skip with “EXIT”.
The display returns to the AIR CALIBRATION menu.
