X5 FastMig
Operating manual - EN
4.6 Installing and cleaning power source air filter (optional)
An optional power source air filter can be purchased separately. The air filter comes with a fixed casing designed to be
mounted directly onto the power source air intake.
Using the optional air filter decreases the rated power levels of the power source as follows (output 40 °C):60% >>>
45% and 100% >>> 100%-20A. This is due to the slightly reduced cooling air intake.
Tools needed:
Installation and replacement
1. Place the air filter assembly onto the power source air intake, and lock it in place with the clips on the edge of the
casing.
© Kemppi
109
1920960 / 2144
