X5 FastMig
Operating manual - EN
2.10 Installing and changing wire (X5 WF 200)
This section describes how to install the wire and spool on X5 Wire Feeder 200.
Install the welding gun to the wire feeder before installing the wire spool.
When changing the wire spool, remove the remaining filler wire from the welding gun and wire feed mechanism
before removing the wire spool.
Always ensure that the feed rolls are suitable for the filler wire (diameter and material) in question. Refer also to
"Installing and replacing feed rolls" on page59.
To remove the wire spool:
1. Open the wire feeder side hatch.
2. Release the hub's lock and push the wire spool locking clips towards the center.
3. Remove the wire spool from the wire feeder.
To install a new wire spool:
1. Open the wire feeder side hatch.
2. If not already, release the hub's lock so that the locking clips can move towards the center.
3. Insert the wire spool onto the hub in the wire feeder.
Ensure that the wire spool is facing the right direction, the filler wire running from the top of the spool to the feed
rolls.
Ensure that the hub locking clips lock once the wire spool is in place.
© Kemppi
48
1920960 / 2144
