2.4 Installing wire feeder with fixed plate
This section describes the fixed installation of X5 Wire Feeder 300 (on top of the power source).
For stacked installation, additional support is required. Read the installation notes here: "Installation" on page22.
Tools needed:
1. Temporarily remove the power source top cover screws.
2. Place the front fixing plate on the power source and secure it in place using two of the power source top cover
screws (M6x30).
