Kemppi X5 FastMig - Wire Feed Mechanism

X5 FastMig
Operating manual - EN
Spool brake adjustment:
1.3.2 Wire feed mechanism
X5 Wire Feeder 200 wire feed mechanism:
1. Drive rolls and drive roll mounting caps
2. Middle guide tube locking clip
3. Middle guide tube
4. Inlet guide tube
5. Pressure handles
6. Pressure rolls and pressure roll mounting pins
